S48152A Vessel Power Battery Pack
- Commodity name： S48152A Vessel Power Battery Pack
- Description
-
Installation method Cabinet/Rack
IP Level IP67
Battery type Lithium iron phosphate
Rated capacity 152Ah
Nominal voltage 51.2V
Rated energy 7782.4Wh
Standard charge/Discharge current 30.6A
Maximum continuous charge/Discharge current 115A
Charging termination voltage 58.4V
Discharge cutoff voltage 40V
Cycle life ≥2000cycles（25℃ 80％）
Internal resistance ≤20mΩ
Dimensions 1094*488*162mm
Communication mode RS485/CAN
Net weight Approx.86kg
Vessel Power Battery Pack is a high-performance, high-reliability battery solution designed specifically for ship power systems.
1. Excellent performance
High energy density
Vessel Power Battery Pack uses advanced battery technology and has a high energy density. This means that more electrical energy can be stored in a limited space, thereby extending the ship's cruising range. Both small yachts and large cargo ships can benefit from it.
High power output
It can provide high power output in a short time to meet the power requirements of ships under conditions such as starting, acceleration, and climbing. Ensure that the ship can operate stably under various complex navigation conditions.
2. Safe and reliable
Multiple safety protections
Built-in multiple safety protection mechanisms, such as overcharge protection, over-discharge protection, short-circuit protection, etc. Effectively prevent dangerous situations from occurring during battery use and ensure the safe navigation of the ship.
High-quality battery materials
High-quality battery materials are selected and strictly tested and screened. These materials have good stability and durability and can adapt to the harsh environment on ships, including high humidity, high salinity, etc.
3. Strong environmental adaptability
Weather resistance
It can work normally under different climatic conditions, whether it is hot tropical waters or cold polar waters. The performance of the battery pack will not be significantly affected by drastic changes in temperature.
Waterproof and moisture-proof
It has excellent waterproof and moisture-proof properties to meet the water splashing, immersion and other situations that may be encountered during ship navigation.
4. Intelligent management
Battery management system (BMS)
Equipped with an advanced battery management system, it can monitor the status of the battery in real time, including power, temperature, voltage, etc. Through intelligent algorithms, it can achieve precise control and optimized management of the battery, and improve the battery life and efficiency.
Vessel Power Battery Pack provides a clean, efficient and reliable power option for the ship industry, which helps to promote the development of ship electrification.
